Description

The Wacker Neuson WL20e Wheel Loader Features –

Innovative technology, proven in the field

• Wacker Neuson is a global innovation leader in electric drives for construction equipment. With the WL20e, we offer you an emission-free solution that has already been time-tested and proven for several years and in many different operations –and which we continuously strive to develop even further. The operator therefore always benefits from the latest technology.
• Up to 5 hours of operation are possible with a fully charged battery, depending on the type of use.

Powerful lithium-ion battery

• Depending on the application and purpose, the appropriate battery size can be selected. A total of three maintenance-free lithium-ion batteries are available: Standard is 14.1 kWh, optionally available are 18.7 kWh or 23.4 kWh.
• A 3 kW onboard charger is installed as standard. Optionally, a second 3 kW onboard charger can be selected to increase the charging power to a total of 6 kW, which is suitable for the medium and large battery to achieve a fast charging time.
• The lithium-ion battery comes with a standard warranty of 36 months or 900 charging cycles (minimum 80% remaining battery capacity).

Easy charging options

• The charging cover can be accessed easily from the outside on the machine. Behind it you will find the socket, the activation switch, and the charge display.
• The charging cable (Type 2 plug on the machine, familiar from the automotive industry), including the control box, is available with a number of different plugs: 230 V / 10 A Schuko, 230 V / 16 A CEE (blue, 3-pole), 400 V / 16 A CEE (red, three-phase AC current, 5-pole), 400 V / 16 A (Type 2 plug wall box, IEC 62196), and other adapter plugs.
• The flexible, selectable charging plugs enable fast and coordinated charging of the selected battery size. In combination with the installed on-board charger, both efficient and safe charging processes are guaranteed.

Comfortable cab

• The cabin of the WL20e comfortably enables year-round use of the machine, e.g. also in cold seasons during winter maintenance. It has been optimized to meet the needs of the operator, offers many new features, enables safe and comfortable working and provides sufficient space for the operator despite its compact design.
• The well thought-out heating concept covers all requirements: Heating standard, comfort heating with even more power, roof panel heating and seat heating. This ensures that the driver can work at a comfortable interior temperature even in cold outside temperatures. In summer, good ventilation is ensured even without air conditioning: Door can be locked on right and left for gap ventilation, door can be opened 180° on right and left and rear window can be opened.
• The low-slung windows and the shortened rear of the machine provide the best all-round visibility, the electrically heated front and rear windows ensure optimum visibility in all weather conditions, and the emergency stop switch under the joystick offers high safety.

EPS folding overhead guard (Easy Protection System)

• Compact wheel loaders can be equipped with the fold-down operator’s canopy EPS (Easy Protection System). This complies with the current European Machinery Directive according to ROPS and FOPS protection. With a few hand movements, the EPS can be prepared manually for a low clearance height.
• EPS increases the flexibility of the machine, as it can even pass through low passages. Also, the application areas of the machine are expanded. In other cases where several machines might have to be used, just one machine can get the work done. At the same time, the operator’s safety remains guaranteed.
